Canadian Solar 590W TopHiKU6 Solar Panel

Description

Canadian Solar 590W TopHiKU6 Solar Panel

The Canadian Solar 590W TopHiKU6 is a high-performance N-type TopCon solar panel designed for maximum energy yield and long-term reliability. Its EVO2 and F30 frame design ensures durability, while advanced cell technology delivers superior efficiency in a wide range of conditions.

---

Key Features

Higher Power Output

• Module output up to 600W

• Efficiency up to 23.2%

• Excellent resistance to LeTID and PID effects

• Low degradation for consistent long-term performance

• Reduced temperature coefficient (-1.29%/°C) for improved results in hot climates

• Lower overall LCOE and system cost

Reliability & Durability

• Ice-ball impact tested (45mm diameter, IEC 61215)

• Minimizes micro-crack effects

• Withstands snow loads up to 5400Pa and wind loads up to 2400Pa

• 12-year warranty on product materials and workmanship

• 30-year linear power warranty

  • First-year degradation ≤ 1%

  • Annual degradation ≤ 0.4%

---

Certifications & Standards

• Management Systems:

  • ISO 9001:2015 (Quality)

  • ISO 14001:2015 (Environmental)

  • ISO 45001:2018 (Health & Safety)

  • IEC 62941:2019 (PV Manufacturing Quality)

• Product Certifications:

  • IEC 61215, IEC 61730, CE, INMETRO, MCS, UKCA, CGC

  • UL 61730, IEC 61701, IEC 62716, IEC 60068-2-68

---

Electrical Data (STC)

• Nominal Max Power: 590W

• Voltage (Vmp): 43.5V

• Current (Imp): 13.57A

• Open Circuit Voltage (Voc): 52.6V

• Short Circuit Current (Isc): 14.06A

• Efficiency: 22.8%

• Operating Temp Range: -40°C to +85°C

• Max System Voltage: 1500V (IEC/UL) / 1000V (IEC/UL)

• Fire Rating: UL Type 1/2 or IEC Class C

• Fuse Rating (Max Series): 25A

• Protection Class: II

• Power Tolerance: 0 to +10W

---

Mechanical Data

• Cell Type: N-Type TOPCon

• Cell Layout: 144 (2 × 72)

• Dimensions: 2,278 × 1,134 × 30 mm

• Weight: 27.6 kg

• Front Glass: 3.2mm tempered, anti-reflective coated

• Frame: Anodized aluminium alloy

• Junction Box: JP68 with 3 bypass diodes

• Cables: 4mm² (IEC) / 12 AWG (UL), length 300mm + 200mm (customizable)

• Connectors: T6 / MC4-EVO2 / MC4-EVO2A

---

Electrical Data (NMOT)

• Nominal Max Power: 446W

• Operating Voltage (Vmp): 41.1V

• Operating Current (Imp): 10.85A

• Open Circuit Voltage (Voc): 49.8V

• Short Circuit Current (Isc): 11.34A

---

Temperature Characteristics

• Pmax Coefficient: -0.29%/°C

• Voc Coefficient: -0.25%/°C

• Isc Coefficient: +0.05%/°C

• Nominal Operating Temp: 41 ± 3°C

---

⚠️ Important:
All solar panels and related systems must be installed by qualified professionals in compliance with local wiring regulations and safety standards. Incorrect installation may result in malfunction or void product warranties.
