Deye 16kW Solar Inverter 1
Deye 16kW Solar Inverter 2
Deye 16kW Solar Inverter 3

Deye 16kW Solar Inverter

R53 149,00
Price incl. VAT

Deye 16kW Solar Inverter

Need help choosing the right Solar equipment? Call us today!

The Deye 16kW hybrid inverter is specifically designed for residential and light commercial use, offering maximum self-consumption of solar energy and enhancing your energy independence. During the daytime, the PV system generates electricity, prioritizing the power supply to your loads. Any surplus energy is efficiently directed to charge the battery via the Deye 16kW Solar Inverter. This stored energy can then be utilized when your loads require it. Additionally, the battery can be charged by a diesel generator, ensuring a continuous power supply during grid blackouts. With the inclusion of an RS485/CAN port, battery communication is seamless and effective, further enhancing the performance of your energy system. Experience optimal efficiency and uninterrupted power with the Deye SUN 16K-SG hybrid inverter.

Key Features:

  • A high-resolution LCD
  • IP65 protection
  • DC couple and AC couple to retrofit existing solar system.
  • You can connect up to 16 Deye Inverters in parallel, making it possible to have AC output of up to 256kW with one input PV array; Support multiple batteries parallel.
  • Max. charging/discharging current of 290A.
  • 6 time periods for battery charging/discharging.
  • Support storing energy from a diesel generator.
  • LCD Touch display and buttons, simple solar system for residential use.
  • Monitoring is possible via a web browser or mobile app, so you can see how your solar system is performing at any time.
  • 5 Year Warranty.

~ Please contact us for a final quote ~

~ Installation is not included ~

This product must be installed by a qualified electrician/technician. All installations must adhere to local wiring regulations and standards. Solar Power Space RSA will not be held liable for any product malfunctions as a result of incorrectly installed systems.
Category:
Tags: , , , ,
Brands:

Description

Deye Hybrid | 16kW | 48V

THE INVERTER

The Deye 16kW Hybrid Inverter is a cutting-edge solution designed to provide solar energy for residential and commercial buildings. With its versatile capabilities, this hybrid inverter offers both on-grid and off-grid power options, ensuring uninterrupted electricity supply even during grid outages. It supports up to 16 units in parallel for efficient operation and features an advanced MPPT tracking algorithm, making it suitable for large-scale PV power plants or residential rooftop systems. Additionally, the Deye Hybrid Inverter supports multiple battery parallel connections and boasts a maximum charging and discharging current of 290A. Whether you’re looking to upgrade an existing PV power plant or seeking a replacement for your current inverter, the Deye 16kW Hybrid Inverter is a reliable and powerful choice that allows you to harness the maximum potential of your solar power.

Technical Data.

  • Model: SUN-16K-SG01LP1-EU
  • Battery Type: Lead-acid or Li-lon.
  • Battery Voltage Range: 40-60V.
  • Max. Charging Current: 290A.
  • Max. Discharging Current: 290A.
  • UPS Power: 16000W.
  • External Temperature Sensor: Yes.
  • Charging Curve: 3 Stages / Equalization.
  • Charging Strategy for Li-Ion Battery: Self-adaption to BMS.

AC Output Data

  • Rated AC Output Power: 16000W
  • AC Output Rated Current: 69.6A
  • Maximum Continuous AC Passthrough: 100A
  • Peak Power (Off Grid): 2 time of rated Power, 5 S
  • Power Factor: 0.8 Leading to 0.8 Lagging
  • Output Frequency and Voltage: 50/60Hz; L/N/PE 220/230VAC (Single Phase)
  • Grid Type: Single Phase

PV String Input Data.

  • Max. DC Input Power: 20800W.
  • Max. DC Input Voltage: 500V.
  • Start-up Voltage: 50V.
  • MPPT Range: 150-425V.
  • Rated DC Input Voltage: 370V.
  • PV Input Current: 26A+26A+26A.
  • Max. PV ISC: 44A+44A+44A.
  • Number of MPPT / Strings per MPPT: 3/2.

General Data.

  • Operating Temperature Range: -45~60º C, >45º C derating.
  • Cooling: Smart cooling.
  • Noise: <30 dB.
  • Communication with BMS: RS485; CAN.
  • Weight: 51.5kg.
  • Size: 464W×798.4H×300Dmm.
  • Protection Degree: IP65.
  • Installation Style: Wall-mounted.
  • Warranty: 5 years.
  • Max. Number of Parallel (PCS): 16.

Environment Limit

  • Operating Temperature Range: -45°C to 60°C
    • Cooling: Smart Cooling (<30 dB)
  • Communication: RS485 / CAN
  • Ingress Protection: IP65
  • Safety Certification: IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2

Efficiency.

  • Max. Efficiency: 97.60%.
  • Euro Efficiency: 96.50%.
  • MPPT Efficiency: 99.90%.

Deye 16kW Hybrid Inverter

Scale Up Over Time

With the flexibility of 2 MPPT’s (Maximum Power Point Trackers), you can start with just one MPPT and expand to utilise the second MPPT at a later date. This scalability allows you to adapt your solar system to your evolving needs and budget.

Need Even More Power

The Deye 16kW Solar Inverter offers the ability to scale up your system by including up to 16 units in parallel. Whether you’re expanding your energy capacity for residential or commercial purposes, this inverter has you covered.

Experience Higher Yields and Reduced Electricity Bills

Improve self-consumption ratio up to 80% for maximum energy utilisation.Reduce your electricity bill with a DC/AC ratio up to 1.3, optimising energy conversion.Designed for double-side PV modular systems, ensuring efficient power generation.Benefit from a Two MPPT design for enhanced performance and flexibility.Achieve maximum efficiency of 97.6% for optimal energy production.

User-Friendly and Convenient

Enjoy easy operation with the LCD touch screen and intuitive buttons.Compatible with both lithium-ion and lead-acid batteries for versatile energy storage options.Monitor your system effortlessly through a web browser or mobile app.

Reliable and Protected

Equipped with PV lightning protection, anti-islanding protection, and leakage current protection.Offers IP65 protection, ensuring durability in various weather conditions.Automatically switches from Grid-Tied to Off-Grid mode within 5ms for uninterrupted power supply.Prevents system feeding into the grid with the zero export function. NRS Approved.Fast reaction time of within 200ms in zero export mode.Smart and Versatile:

Programmable charging and discharging schedules for customised energy management.Compatible with both wind turbines and solar panels as DC input power sources.Paralleling capability of up to 16 units for higher system power.Allows retrofitting of existing solar systems into energy storage systems.

Experience the versatility and scalability of the Deye 16kW Solar Inverter, empowering you to customise and optimise your solar energy system over time. Enjoy reliable power, uninterrupted performance, and the flexibility to adapt to your energy needs.

PRODUCT SPECIFICATIONS

Weight 56.4 kg
Dimensions 65.5 × 43 × 99 cm
Brand Deye
Product Type Inverter
System Phase Single Phase
System Type Hybrid
kW Size 16kW
Max Parallel Units 16 Inverters
Maximum PV Array Power 20800W/inverter
Mounting Wall Mount
Voltage 48V
Warranty 5 Years
