Deye 5kW Solar Inverter

R17 899,00
Price incl. VAT

Deye 5kW Solar Inverter

Need help choosing the right Solar equipment?

The Deye 5kW Hybrid Inverter is a cutting-edge solution for residential and commercial energy systems. With its advanced hybrid technology, this inverter seamlessly integrates solar power, battery storage, and grid electricity to provide a reliable and efficient energy management system. The 5kW power rating ensures ample capacity for various loads, making it suitable for a wide range of applications. Equipped with intelligent features such as real-time monitoring, energy optimization, and grid backup capabilities, the Deye 5kW Hybrid Inverter offers enhanced control and flexibility. Experience the benefits of clean energy and energy independence with the Deye 5kW Hybrid Inverter.

  • Rated power 5KW
  • Voltage: 48V
  • LCD Touch screen and buttons, easy operation
  • MPPT ranges 125V~425V
  • High-frequency inverter
  • Pure sine wave AC output
  • Solar and utility grid can power loads at the same time
  • With CAN/RS485 for BMS communication
  • Parallel operation up to 9 units
  • Web browser and mobile App monitoring supported
  • 5 Year Warranty

~ Please contact us for a final quote ~

~ Installation is not included ~

This product must be installed by a qualified electrician/technician. All installations must adhere to local wiring regulations and standards. Solar Power Space RSA will not be held liable for any product malfunctions as a result of incorrectly installed systems.
Category:
Tags: , , , ,
Brands:

Description

Deye Hybrid | 5kW | 48V

THE INVERTER

Experience the incredible versatility of the Deye 5kW Solar Inverter with its innovative blending technology and the ability to cater to both Essential and Non-Essential Loads.

This exceptional inverter offers a wide range of applications:

  1. Grid-Tied Inverter: Utilise the inverter with solar panels only, seamlessly connecting to the grid to maximise your solar energy production and reduce your reliance on the utility.
  2. Load Shedding Solution: Use the inverter with batteries only, providing a reliable backup power source during load shedding or grid outages. Keep your essential loads powered and maintain your daily activities uninterrupted.
  3. Hybrid Solution: Enjoy the best of both worlds by harnessing the power of solar energy and the grid. The Deye 5kW Solar Inverter enables you to charge your batteries using solar panels and the grid, ensuring a continuous power supply during outages or load shedding.

Battery Input Data

  • Battery Type: Lead-acid or Li-lon.
  • Battery Voltage Range (V): 40-60V.
  • Max.Charging Current (A): 90A.
  • Max.Discharging Current (A): 90A.
  • Charging Curve: 3 Stages/Equalization.
  • External Temperature Sensor: Optional.
  • Charging Strategy for Li-Ion Battery: Self-adaption to BMS.

PV String Input Data

  • Max. DC Input Power (W): 4680W.
  • PV Input Voltage (V): 370V (100V – 500V).
  • MPPT Range (V): 125V – 425V.
  • Full Load DC Voltage Range: 240V – 425V.
  • Start-up Voltage (V): 150V.
  • PV Input Current (A): 11A.
  • No.of MPPT Trackers: 2.
  • No.of strings per MPPT Tracker: 1+1.

AC Output Data

  • Rated AC Output and UPS Power (W): 36000W.
  • Max. AC Output Power (W): 3960W.
  • Peak Power (off grid): 2 times of rated power, 10 S.
  • AC Output Rated Current (A): 15.7A.
  • Max. AC Current (A): 18A.
  • Max Continuous AC Passthrough (A): 35A.
  • Power Factor: 0.8 leading to 0.8 lagging.
  • Output Frequency and Voltage: 50/60Hz:220/230/240V ac (Single Phase).
  • Grid Type: Single Phase.
  • Current Harmonic Distortion: THD<3%(Linear Load<1.5%).

General Data

  • Operating Temparature Range (C): -25-60C, >45C Derating
  • Cooling: Fan
  • Noise(dB): <30
  • Communication with BMS: RS485;CAN
  • Weight (Kg): 20.5
  • Size (Length x Widthx Height mm): 580 x 330 x 208mm
  • Protection Degree: IP65
  • Installation Style: Wall mounted
  • Warranty: 5 Years
Essential & Non-Essential Loads
  • Separate and prioritize your heavy appliances, saving battery backup for essential loads.
Completely Autonomous
  • The Autonomous Hybrid Solar Inverter effortlessly keeps the lights on and your bills to zero. Smart technology ensures the inverter knows what to do and when to do it.
Robust & Reliable
  • The Fusion inverter boasts a great design and exceptional quality, making it a preferred choice. Stable and robust performance when configured correctly.
Compatibility
  • Compatible with most AGM and Lithium-ion batteries on the market, ensuring flexibility. Years of development guarantee stability and robustness when configured correctly.
Blending AC & DC
  • True Hybrid inverter that efficiently blends DC (panels & batteries) with the AC grid power.
Phone App
  • Monitor your consumption remotely with the Solar System monitoring iPhone or Android app.
LCD Screen
  • Change settings and monitor the inverter’s performance with the convenient LCD display.
5-Year Warranty
  • Enjoy peace of mind with a standard 5-year warranty, ensuring reliable performance.

PRODUCT SPECIFICATIONS

Weight 25.1 kg
Dimensions 79 × 36 × 50 cm
Brand Deye
Product Type Inverter
System Phase Single Phase
System Type Hybrid
kW Size 5kW
Max Parallel Units 9 Inverters
Maximum PV Array Power 6500W/inverter
Mounting Wall Mount
Voltage 48V
Warranty 5 Years
