Deye 8kW Solar Inverter

R32 499,00
Price incl. VAT

Deye 8kW Solar Inverter

Need help choosing the right Solar equipment? Call us today!

The Deye 8kW Hybrid Inverter is a cutting-edge solution for residential and commercial energy systems. With its advanced hybrid technology, this inverter seamlessly integrates solar power, battery storage, and grid electricity to provide a reliable and efficient energy management system. The 5kW power rating ensures ample capacity for various loads, making it suitable for a wide range of applications. Equipped with intelligent features such as real-time monitoring, energy optimization, and grid backup capabilities, the Deye 5kW Hybrid Inverter offers enhanced control and flexibility. Experience the benefits of clean energy and energy independence with the Deye 5kW Hybrid Inverter.

  • Rated power 8KW
  • Voltage: 48V
  • LCD Touch screen and buttons, easy operation
  • MPPT ranges 125V~425V
  • High-frequency inverter
  • Pure sine wave AC output
  • Solar and utility grid can power loads at the same time
  • With CAN/RS485 for BMS communication
  • Parallel operation up to 16 units
  • Set system parameters remotely with FREE SOLARMAN PRO App
  • 5 Year Warranty

~ Please contact us for a final quote ~

~ Installation is not included ~

This product must be installed by a qualified electrician/technician. All installations must adhere to local wiring regulations and standards. Solar Power Space RSA will not be held liable for any product malfunctions as a result of incorrectly installed systems.
Category:
Tags: , , ,
Brands:

Description

Deye Hybrid | 8kW | 48V

THE INVERTER

Experience the incredible versatility of the Deye 8kW Solar Inverter with its innovative blending technology and the ability to cater to both Essential and Non-Essential Loads.

This exceptional inverter offers a wide range of applications:

  1. Grid-Tied Inverter: Utilise the inverter with solar panels only, seamlessly connecting to the grid to maximise your solar energy production and reduce your reliance on the utility.
  2. Load Shedding Solution: Use the inverter with batteries only, providing a reliable backup power source during load shedding or grid outages. Keep your essential loads powered and maintain your daily activities uninterrupted.
  3. Hybrid Solution: Enjoy the best of both worlds by harnessing the power of solar energy and the grid. The Deye 8kW Solar Inverter enables you to charge your batteries using solar panels and the grid, ensuring a continuous power supply during outages or load shedding.

Battery Input Data

  • Battery Type: Lead-acid or Li-lon.
  • Battery Voltage Range (V): 40-60V.
  • Max.Charging Current (A): 190A.
  • Max.Discharging Current (A): 190A.
  • Charging Curve: 3 Stages/Equalization.
  • External Temperature Sensor: Optional.
  • Charging Strategy for Li-Ion Battery: Self-adaption to BMS.

PV String Input Data

  • Max. DC Input Power (W): 10400W.
  • PV Input Voltage (V): 370V (100V – 500V).
  • MPPT Range (V): 125V – 425V.
  • Full Load DC Voltage Range: 240V – 425V.
  • Start-up Voltage (V): 150V.
  • PV Input Current (A): 18A+18A.
  • No.of MPPT Trackers: 2.
  • No.of strings per MPPT Tracker: 2+2.

AC Output Data

  • Rated AC Output and UPS Power (W): 8000W.
  • Max. AC Output Power (W): 8800W.
  • Peak Power (off grid): 2 times of rated power, 10 S.
  • AC Output Rated Current (A): 33.4A/35A.
  • Max. AC Current (A): 38.3A/40A.
  • Max Continuous AC Passthrough (A): 50A.
  • Power Factor: 0.8 leading to 0.8 lagging.
  • Output Frequency and Voltage: 50/60Hz; 120/240Vac(split phase), 208Vac(2/3 phase),230Vac(single phase).
  • Grid Type: Split phase / 2/3 phase / Single Phase.
  • Current Harmonic Distortion: THD<3%(Linear Load<1.5%).

General Data

  • Operating Temparature Range (C): -25-60C, >45C Derating
  • Cooling: Fan
  • Noise(dB): <30
  • Communication with BMS: RS485;CAN
  • Weight (Kg): 20.5
  • Size (Length x Widthx Height mm): 670 x 420 x 233mm
  • Protection Degree: IP65
  • Installation Style: Wall mounted
  • Warranty: 5 Years

Deye 8kW Hybrid Inverter

Scale Up Over Time

With the flexibility of 2 MPPT’s (Maximum Power Point Trackers), you can start with just one MPPT and expand to utilise the second MPPT at a later date. This scalability allows you to adapt your solar system to your evolving needs and budget.

Need Even More Power

The Deye 8kW Solar Inverter offers the ability to scale up your system by including up to 16 units in parallel. Whether you’re expanding your energy capacity for residential or commercial purposes, this inverter has you covered.

Experience Higher Yields and Reduced Electricity Bills

Improve self-consumption ratio up to 80% for maximum energy utilisation.Reduce your electricity bill with a DC/AC ratio up to 1.3, optimising energy conversion.Designed for double-side PV modular systems, ensuring efficient power generation.Benefit from a Two MPPT design for enhanced performance and flexibility.Achieve maximum efficiency of 97.6% for optimal energy production.

User-Friendly and Convenient

Enjoy easy operation with the LCD touch screen and intuitive buttons.Compatible with both lithium-ion and lead-acid batteries for versatile energy storage options.Monitor your system effortlessly through a web browser or mobile app.

Reliable and Protected

Equipped with PV lightning protection, anti-islanding protection, and leakage current protection.Offers IP65 protection, ensuring durability in various weather conditions.Automatically switches from Grid-Tied to Off-Grid mode within 5ms for uninterrupted power supply.Prevents system feeding into the grid with the zero export function. NRS Approved.Fast reaction time of within 200ms in zero export mode.Smart and Versatile:

Programmable charging and discharging schedules for customised energy management.Compatible with both wind turbines and solar panels as DC input power sources.Paralleling capability of up to 16 units for higher system power.Allows retrofitting of existing solar systems into energy storage systems.

Experience the versatility and scalability of the Deye 8kW Solar Inverter, empowering you to customise and optimise your solar energy system over time. Enjoy reliable power, uninterrupted performance, and the flexibility to adapt to your energy needs.

PRODUCT SPECIFICATIONS

Weight 35.7 kg
Dimensions 89 × 36.7 × 60 cm
Brand Deye
Product Type Inverter
System Phase Single Phase
System Type Hybrid
kW Size 8kW
Max Parallel Units 16 Inverters
Maximum PV Array Power 10400W/inverter
Mounting Wall Mount
Voltage 48V
Warranty 5 Years
