Sunsynk 3.6kW 48V Single Phase Hybrid Inverter

R 17,932.00R 22,870.00 (-22%)

In stock

Sunsynk 3.6kW 48V Single Phase Hybrid Inverter

Main Features

  • Easy and simple to understand display.
  • Supporting Wi-Fi or GSM monitoring.
  • Visual power flow screen.
  • Built-in 2 strings of MPP trackers.
  • Smart settable 3-stage MPPT charging for optimized battery performance.
  • Auxiliary load function.
  • Parallel / multi-invert function grid-tied and off-grid.

Specifications

  • Inputs:
    • PV solar
    • AC grid power
    • Batteries
    • Generator
  • Output voltage – 220/230/240Vac
  • Continuous power – 3600W
  • Backup power – 3600W
  • DC – 48V
  • Battery charger – 90A
  • Transfer time <= 10ms
  • Battery charger adjustable for battery bank size and type
    • Can charge Lead Acid and Li-ion batteries
    • Li-ion battery charging self-adapts to BMS
  • Solar Input
    • Max power input – 4680W
    • Max V DC input – 370V (100V~500V)
    • Max current input – 2 x 11A
    • MPPTs – 1
    • MPPT Range – 125~425V
  • Multi-core processor design and advanced MPPT control
  • High reliability and response speed
  • Programmable export
  • Works parallel on or off-grid
  • Single-phase operation
  • Multiple operating modes:
    • Grid-tie only
    • Hybrid
    • Off-grid
    • Battery only
  • Additional features
    • AC couple – For additional PV input
    • 6 stages time of use settings
  • ​IP65
  • Warranty: 5 years.

Important:

All solar products, power systems, water heating and gas products and their components must be installed by appropriately qualified personnel. All installations must adhere to local wiring regulations and standards. Solar Power Space Online will not be held liable for any product malfunctions as a result of incorrectly installed systems.
