Victron MultiPlus-II 48/8000/110-100/100

Description

Victron MultiPlus-II 48/8000/110-100 Inverter Charger – 8kVA 48V

The Victron MultiPlus-II 48/8000/110-100 is a powerful all-in-one inverter and charger system for professional off-grid, grid-tied, or backup energy applications. Designed for high-performance solar energy storage and generator integration, this unit combines the trusted features of the original MultiPlus with advanced grid compliance, UPS functionality, and intelligent remote monitoring.

Key Features:

 8kVA Continuous Inverter Power
Delivers up to 6400W continuous output power at 25°C and a peak of up to 15,000W, ideal for demanding residential or commercial loads.

 Built-In UPS Function (<20ms Transfer)
Ensures computers and sensitive electronics continue operating without disruption during outages — automatic, seamless switch.

 PowerAssist & PowerControl
Limits generator or grid input to prevent overloads, using battery support when needed — ideal for homes with limited Eskom supply or generators.

 ESS Ready – Dynamic Energy Storage System
Supports advanced hybrid setups that prioritize solar, grid, or battery based on usage, cost, and generation. Compatible with grid-tied inverters or MPPTs.

 Parallel & 3-Phase Ready
Can be expanded with identical units to deliver three-phase power or high-capacity setups — perfect for modular and scalable installations.

 Remote Monitoring & Control
Connects to the Victron VRM Portal or VictronConnect App via Cerbo GX, Color Control GX, or Ekrano GX. View live data, system history, and configure settings remotely.

 Smart Battery Charging
Supports lithium-ion and lead-acid batteries with programmable charge profiles, temperature sensors, and up to 110A charge current.

 Dual AC Outputs
Prioritize essential vs. non-essential loads — AC1 supports UPS loads; AC2 only runs when grid/generator is present (e.g. geysers).

 Robust & Reliable Build
IP21-rated steel enclosure. Fan-assisted cooling and advanced protections against over-temperature, short circuits, high/low voltage, and more.

Specifications Summary:

• Continuous Power: 8000 VA / 6400 W @ 25°C
• Peak Power: 15,000 W
• Battery Voltage: 48V
• Max Battery Charge Current: 110A
• Max Efficiency: 95%
• Inverter Topology: Isolated
• Transfer Time: <20 ms
• DC Input Range: 38–66V
• AC Input Voltage: 230V ±10%
• AC Frequency: 50 Hz (adjustable to 60 Hz)
• Dimensions: 642 x 363 x 206 mm
• Weight: 42 kg
• Protection: Short circuit, overload, temp, over/under-voltage
• Monitoring: VRM, VictronConnect, GX Devices
• Country Approvals: AS/NZS 4777.2:2020+A1+A2, EN/IEC Compliant

Applications:

• Off-grid homes and farms
• Backup power systems for critical loads
• Marine, vehicle, and containerized setups
• Commercial installations needing high-reliability UPS

What You’ll Need:

• Compatible battery bank (Lithium or Lead-Acid)
• Optional GX device (e.g. Cerbo GX) for VRM monitoring
• MK3-USB interface (for configuration via PC)

 • Optional external current transformer for PowerAssist (up to 100A)
