Name: Victron Quattro 48/15000 – 200-100/100
Price: 48799.00 ZAR
Availability: InStock

Description

Victron Energy – Quattro 48/15000/200-100/100 (230V VE.Bus)

Multifunctional Inverter/Charger with Dual AC Input

The Victron Quattro is a high-performance inverter/charger that combines advanced power management, seamless switching, and unparalleled scalability. Designed for demanding off-grid, backup, and grid-interactive systems, it ensures uninterrupted power supply and maximum flexibility in both residential and commercial applications.

Key Features

Dual AC Inputs & Automatic Transfer Switching

Accepts two independent AC sources (e.g., grid + generator, or dual generators).
Integrated transfer switch ensures seamless switching to the active source.
Main Output (no-break): supplies critical loads instantly during a power failure (<20 ms switching time).
Second Output: active only when AC input is available; ideal for non-essential loads (e.g., water heaters, air conditioning).

PowerAssist & PowerControl Technology

PowerControl: prevents overload of limited power sources (generator, grid, or shore supply) by automatically adjusting charging current.
PowerAssist: supplements insufficient generator/grid power with battery support during peak demand, then recharges when loads decrease.

Massive Power & Expandability

Continuous output power: 15 kVA (12 kW).
Parallel operation: up to 6 Quattros for 90 kVA / 72 kW output.
Three-phase capability: configure three units for three-phase supply, expandable up to 144 kVA / 120 kW.
Split-phase operation: possible with two stacked units (120-0-120V).

Solar & ESS Integration

Works in off-grid or grid-tied systems with PV inverters or MPPT Solar Chargers.
Compatible with Victron ESS (Energy Storage System) applications.
Provides uninterrupted AC power even during grid outages.

Remote Monitoring & Control

Local and remote access via:
- VRM Portal (free, worldwide access).
- VRM App (iOS/Android).
- GX devices (Cerbo GX, Color Control GX, Venus GX, Octo GX, CANvu GX).
On-site configuration options: DIP switches, VE.Bus Quick Configure, and System Configurator software.
Remote configuration possible when connected to Ethernet.

Technical Specifications – Quattro 48/15000/200-100/100

Category	Specification
Inverter
DC Input Voltage Range	38 – 66 V DC
Continuous Output Power @ 25°C	15,000 VA / 12,000 W
Continuous Output Power @ 40°C	11,000 W
Continuous Output Power @ 65°C	9,000 W
Peak Power	25,000 W
Output Voltage	230 VAC ± 2%
Output Frequency	50 Hz ± 0.1%
Efficiency	Up to 96%
Zero Load Power	70 W
AES Mode Consumption	40 W
Search Mode Consumption	20 W
Charger
AC Input Voltage Range	187 – 265 VAC
Input Frequency	45 – 65 Hz
Max Battery Charge Current	200 A
Charge Voltage Absorption	57.6 V
Charge Voltage Float	55.2 V
Storage Mode Voltage	52.8 V
Battery Temp Sensor	Yes
Power Factor	1
General
Transfer Switch	100 A
AC Inputs	2 (100 A each)
AC Outputs	2 (main + auxiliary)
Programmable Relay	Yes
External Current Sensor	Optional
Operating Temperature	-40°C to +65°C (fan-assisted cooling)
Humidity (non-condensing)	Max 95%
Protection Category	IP21
Weight	~99 kg
Dimensions (HxWxD)	840 x 565 x 444 mm
Standards & Safety
Safety	EN-IEC 60335-1, EN-IEC 62109-1/2
EMC	EN 55014-1, EN 61000-6-3, EN 61000-6-2
Anti-Islanding	VDE-AR-N 4105, AS/NZS 4777.2, G59/3, and more
Warranty	5 years (extendable to 10 years)

Applications

Off-grid and backup power systems
Large residential or commercial ESS installations
Marine and mobile power solutions
Industrial backup systems requiring high surge capacity
